According to the type of working power supply: can be divided into DC motor and AC motor.
keyword：Motor,YE2,YE3
Tel/Wechat/Whatsapp
Detail
Overview of characteristics
General purpose aluminum-cased motors shall be rated for maximum continuous rating and capable of operating in the S1 operating regime.
S1-Continuous operation: the motor is operated at a constant load for a period of time sufficient to achieve thermal stabilization.
S2-Short-time operating system: the motor is operated under a constant load for a given time, which is not sufficient to achieve thermal stability, followed by power failure, and then stopping rotation for a sufficient time to allow electric cooling to ambient temperature.
In the rated voltage, rated frequency, the use of ambient air temperature does not exceed -15 ° C ~ 40 ° C
The sea wave height does not exceed 1000 meters. Insulation class F, stator winding temperature rise test 80 K. Shell protection: IP54, IP55, IP56.
Cooling method: IC411.
The motors produced by our company are S1 working system. Shell protection without special requirements are produced according to IP54.
Overload coefficient: λ=Tmax /TN
●Note
1、Tmax of three-phase motor is proportional to the square of voltage, so it is sensitive to voltage fluctuation.
2、When working, make sure the torque of the load TL<Tmax, otherwise the motor will stop or overheat and burn out.
TECHNICAL DATE
1500r/min 380V 50Hz
| Model | Rated power | Rated speed Ist/IN | efficiency η(%) | Factor (CosΦ) | Current rating | Rated torque | Locked torque | Max torque | Locked current | |
| KW | HP | Rated torque | Rated torque | Rated torque | ||||||
|
YE2-63M1-4 |
0.12 |
0.18 |
1310 |
57.0 |
0.72 |
0.44 |
0.87 |
2.10 |
2.2 |
4.4 |
|
YE2-63M2-4 |
0.18 |
0.25 |
1310 |
60.0 |
0.73 |
0.62 |
1.31 |
2.10 |
2.2 |
4.4 |
|
YE2-71M1-4 |
0.25 |
0.37 |
1330 |
65.0 |
0.74 |
0.79 |
1.80 |
2.10 |
2.2 |
5.2 |
|
YE2-71M2-4 |
0.37 |
0.55 |
1330 |
67.0 |
0.75 |
1.12 |
2.66 |
2.10 |
2.2 |
5.2 |
|
YE2-801-4 |
0.55 |
0.75 |
1390 |
73.0 |
0.75 |
1.57 |
3.78 |
2.30 |
2.3 |
6.6 |
|
YE2-802-4 |
0.75 |
1 |
1390 |
79.6 |
0.76 |
1.88 |
5.12 |
2.30 |
2.3 |
6.6 |
|
YE2-90S-4 |
1.1 |
1.5 |
1440 |
81.4 |
0.77 |
2.67 |
7.30 |
2.30 |
2.3 |
6.8 |
|
YE2-90L-4 |
1.5 |
2 |
1440 |
82.8 |
0.77 |
3.57 |
9.95 |
2.30 |
2.3 |
7.0 |
|
YE2-100L1-4 |
2.2 |
3 |
1440 |
84.3 |
0.81 |
4.90 |
14.60 |
2.30 |
2.3 |
7.6 |
|
YE2-100L2-4 |
3 |
4 |
1440 |
85.5 |
0.82 |
6.50 |
19.90 |
2.30 |
2.3 |
7.6 |
|
YE2-112M-4 |
4 |
5.5 |
1440 |
86.6 |
0.82 |
8.56 |
26.50 |
2.20 |
2.3 |
7.8 |
|
YE2-132S-4 |
5.5 |
7.5 |
1450 |
87.7 |
0.83 |
11.5 |
36.20 |
2.00 |
2.3 |
7.9 |
|
YE2-132M-4 |
7.5 |
10 |
1450 |
88.7 |
0.84 |
15.3 |
49.40 |
2.00 |
2.3 |
7.5 |
|
YE2-160M-4 |
11 |
15 |
1460 |
89.8 |
0.84 |
22.2 |
72.00 |
2.20 |
2.3 |
7.7 |
|
YE2-160L-4 |
15 |
20 |
1460 |
90.6 |
0.85 |
29.6 |
98.10 |
2.20 |
2.3 |
7.8 |
|
YE2-180M-4 |
18.5 |
25 |
1470 |
91.2 |
0.86 |
35.8 |
120.20 |
2.00 |
2.3 |
7.8 |
|
YE2-180L-4 |
22 |
30 |
1470 |
91.6 |
0.86 |
42.4 |
142.90 |
2.00 |
2.3 |
7.8 |
1000r/min 380V 50Hz
| Model | Rated power | Rated speed Ist/IN | efficiency η(%) | Factor (CosΦ) | Current rating | Rated torque | Locked torque | Max torque | Locked current | |
| KW | HP | Rated torque | Rated torque | Rated torque | ||||||
|
YE2-90S-6 |
0.75 |
1 |
930 |
75.9 |
0.72 |
2.09 |
7.7 |
2.0 |
2.1 |
6.0 |
|
YE2-90L-6 |
1.1 |
1.5 |
940 |
78.1 |
0.72 |
2.97 |
11.2 |
2.0 |
2.1 |
6.0 |
|
YE2-100L-6 |
1.5 |
2 |
940 |
79.8 |
0.75 |
3.80 |
15.2 |
2.0 |
2.1 |
6.5 |
|
YE2-112M-6 |
2.2 |
3 |
960 |
81.8 |
0.76 |
5.38 |
21.9 |
2.0 |
2.1 |
6.6 |
|
YE2-132S-6 |
3 |
4 |
960 |
83.3 |
0.76 |
7.20 |
29.8 |
2.0 |
2.1 |
6.8 |
|
YE2-132M1-6 |
4 |
5.5 |
960 |
84.6 |
0.76 |
9.45 |
39.8 |
2.0 |
2.1 |
6.8 |
|
YE2-132M2-6 |
5.5 |
7.5 |
960 |
86.0 |
0.77 |
12.6 |
54.7 |
2.0 |
2.1 |
7.0 |
|
YE2-160M-6 |
7.5 |
10 |
970 |
87.2 |
0.78 |
16.8 |
73.8 |
2.0 |
2.1 |
7.0 |
|
YE2-160L-6 |
11 |
15 |
970 |
88.7 |
0.78 |
24.2 |
108.3 |
2.0 |
2.1 |
7.2 |
|
YE2-180L-6 |
15 |
20 |
970 |
89.7 |
0.81 |
31.4 |
147.7 |
2.0 |
2.1 |
7.3 |
